Cornet Electrosmog Meter
Dual-mode RF/LF Electrosmog Field Strength Power Meter
~~~ Model No. ED-85ExPlus ~~~
with external SMA connector, Frequency display
and Data Logging/recording/USB interface to PC
Advanced communication and Network solutions
Affordable, Pocket Size, Handheld, High performance
EMF/RF/LF Meter !
Unique, handy tool for your personal Electromagnetic wave exposure detection and level measurement. Highly sensitive and Accurate indicators for your defense on RF and LF radiation pollutions.
Electromagnetic Radiation (EMF) is always around our environment.
You can measure the amount of EMF around your home, office, children's school, etc!
The ED-85EXPlus Electrosmog meter is a Dual-mode device for quick measurement of both High frequency (RF) Electromagnetic wave field strength/power density level, and Low frequency (LF) Magnetic field level(Gauss, Tesla) for living environments. It is an excellent device for individual or company with Electromagnetic wave safety concerns. It has RF bandwidth (SMA connector direct input ) of 1MHz to 8GHz with high sensitivity -70dBm,(0.05uw/m² to 1.8w/m²), and LF bandwidth of 50Hz to 10KHz (or 50Hz to 1KHz) with sensitivity of 0.1uT to 60uT(1mG-600mG) or 0.01uT to 1uT(0.1mG to 10mG). Data Logging function is also included.
Applications:
- High frequency RF Electromagnetic wave field strength and power density measurement
- Low frequency LF Magnetic field measurement (Gauss meter function)
- Mobile phone base station antenna radiation power density measurement
- Wireless communications, Analog & Digital RF (AM/FM, TDMA, GSM, DECT, CDMA, 3G, 4G, 5G)
- RF power measurement for transmitters
- Wireless LAN (Wi-Fi), Bluetooth, Ultra-wide-band detection, installation, optimization
- Spy camera, wireless bug finder, IOT devices
- Cellular/Cordless phone radiation safety level, Electrical Utilities SMART METER radiation level
- AC power line, power Transformer, motors and small appliance EMF
- Microwave oven leakage detection
- Personal living environment EMF safety evaluation
Features:
- Two operation mode: RF power meter mode and LF Gauss meter mode
- Sensor type: Electric field sensor and Magnetic field sensor
- Frequency range & Sensitivity:
- RF: 1MHz to 8GHz (SMA connector direct input)
(-65dBm to +5dBm),(0.18uw/m2 to 1.8w/m2), (0.008v/m to 26.2v/m), -- (calibrated)
-70dBm ( 0.05uw/m2 )(0.004v/m) -- (uncalibrated)
*RF frequency range for field strength measurement is depend on the external antenna used.
- LF1: 50Hz to 10KHz (0.1uT to 60uT), (1mG to 600 mG)
- LF2: 50Hz to 1KHz (0.01uT to 1uT), (0.1mG to 10mG)
- Frequency display: 100MHz–2.7GHz for field strength measurement, (from internal build-in antenna only, not from SMA connector direct input); -35dBm minimum signal level required.
- Input Impedance: 50 Ohms
- Connector type: SMA female
- RF Peak power measurement: 0.05uw/m² to 1.8w/m² (with external antenna for RF field strength ); 0.004V/m to 26.2V/m (with external antenna for RF field strength )
- Display type: digital LCD graphic display
- Unit of measurements: dBm, mw/m2, v/m, uT, mG, MHz
- LCD back light: 15 seconds auto-off and manual on/off control
- Display of data: LCD 4 and 5 digit, 8 LED color segment, Moving Histogram (level/time) of previous 30 recorded data, Analog segment bar
- Data update rate: Sampling rate: 10,000/sec, Display update rate: 2/sec
- Error rate: RF: +/- 1.5dBm, LF: 20%
- Functions: Hold, Max, Average, Sound signature, Alarm, Frequency
- Sound & Alarm: Sound on/off/volume control, programable Alarm triggering level
- Safety standard indication: 3 safety range indication by 3 Red LED, adjustable LED level
- Data Logging: 1000 data storage point memory for logging/recording measured RF signal level
- Small, compact handheld design, 69mmx130mm
- Battery used: 9V alkaline battery or external power supply through USB port (5V)
- Battery life: >20 hours (battery & USB cable is not included in shipment)
- Internal antenna: internal build-in antenna for Frequency display use only
- External antenna: External whip antenna is included. Optional Log periodic antenna available (not included)
~~~ 01 Year Manufacturer Warranty ~~~
